500-1000-1500L/hour Continues Ball Mill Machine
Ball MillSpecifications
| Model | 500L | 1000L | 1500L |
| Capacity(kg/hour) | 500 | 1000 | 1500 |
| Main Moter Power(kw) | 6 | 9 | 9 |
| Balls Quantity | 750 | 1000 | 1300 |
| Grinding Fineness(micron) | 18-22 | 18-22 | 18-22 |
| Weight(kg) | 4100 | 4900 | 5200 |
| Outside dimensions(mm) | 900×1800×2800 | 1000×2000×3100 | 1000*2000*3100 |
Description
Our Continuous Ball Mill is the preferred solution for fine grinding of compounds, spreads, fillings, nut pastes and other fat-based masses. Its unique grinding chamber allows one-step grinding to a fineness of 18-22 microns at the lowest product temperature.
Three models deliver 500, 1000 and 1500 kg/hour with main motor power of 6-9kW and steel ball loads of 750-1300kg. Weight ranges from 4100kg to 5200kg.
A PLC control system, inside and outside cooling, exhaust system and magnetic filter ensure stable, hygienic continuous production.
Features
It can produce different products, like chocolate mass, cocoa mass, creams for filling and nuts paste, etc;
Capacity ranges from 300kg/batch to 1500kg/h, which can meet different customer's demand;
For 300kg/batch ball mill, it can work with conche refiner to improve grinding efficiency and flavors of chocolate;
For continuous ball mill, the main shaft is hollow and with cooling water circulation to promise the quality of refined chocolate.
With level sensors on buffer tank to guarantee continuous production;
We developed the design of rods on shaft for avoiding the leakage.
Product Advantages
Our chocolate ball mill is not only applied to producing chocolate mass or cocoa mass, but also to nuts paste or fillings. So it's suitable for chocolate manufacturers, cocoa processors and bakery manufacturers. We have 300kg/batch to 1500kg/h which can meet a wide rang of customers' demand. Moreover, we have 20L ball mill for beginners and chocolate shops.
Our continuous ball mill is one pass, which means the raw materials does not need to be circulated between conche refiner and ball mill or inner circulation. So it will improve the grinding efficiency, save the energy and labor cost. The main shaft is hollow and circulated with cooling water during ball mill is working. It will bring high quality of refined products for customer, since the inner temperature is controlled in proper range. The advantages of our 300kg/batch ball mill have separated heating and cooling; products can be inner circulation or outer circulation between conch refiner and ball mill; belt transmission, which brings high efficiency and low noise.
